Model: HD4P-12000
Usually Ships Within
A similar product can be found HEREThe Titan 12,000 lb capacity 4 post lift is power meets size. This cable driven 4 post lift features a single cylinder stowed underneath the diamond plate track with a simple lever release system to unlock the safety locks. At nearly 3,000 lbs, the Titan 12k is the most robust 4 post we offer. Call or email us today for a shipping quote as our shopping cart cannot accurately compute freight shipping quotes.
KEY BENEFITS• 12,000 pound lifting capacity• Warranty: 5 year structural / 1 year parts• Ideal for auto passenger cars & light duty trucks
Show more
• Ramp length: 38"• Overall height: 88"• Overall width: 137"• Runway width: 19.25"• Overall length: 195.25"• Lifting speed: 51 sec• Load capacity: 12,000 lb• Max lifting height: 67"• Lowered runway height: 6"• Width between runways: 48"• Width between columns: 118.5"• Max drive-thru clearance: 104.5"• Max clearance under runway: 63"• Runway length (no ramp): 191.25"• Power supply: 220V-1PH-60HZ-20AMP• Concrete spec. min: 4" reinforced @ 3,000 PSI• Uses AW-32 or ISO-32 / 10 weight hydraulic fluid
• Download the installation manual HERE
• Ships 2,334 lbs. at 190" x 24" x 33" Class 77• Must ship to a business with forklift• Residential deliveries not possible• Can be picked up at local terminal• Pickup in Greenwood, IN for $279
