[DISCONTINUED] Norco 50 Ton Cylinder

Model: 950005

Shipping upgrades offered in cart page


This is the Norco 50 Ton Cylinder. It features Nickel plating on the cylinder pistons to inhibit rusting, a baked enamel exterior finish for increased corrosion resistance, and heavy duty return springs that provide consistent performance. Norco Cylinders comply with ANSI B 30.1. Order yours today!

• Cylinders comply with ANSI B 30.1
• Polyurethane seals and wipers provide high cycle life
• Heavy duty return springs provide consistent performance
• Nickel plating on most cylinder pistons inhibits rusting
• Baked enamel exterior finish for increased corrosion resistance
• Unique piston and cylinder bearings absorb eccentric load stresses
• High flow quick connecting coupler and dust cap included on all models
• Optional hose and couplers to connect the pump to the cylinder available

Show more























  2-3/8" Stroke   6-1/4" Stroke
  • Stroke: 2.38"
  • Min height: 4.81"
  • Max height: 7.19"
  • Oil cap: 22.91 (cubic in.)
  • Cylinder bore diameter: 9.63"
  • Outside piston diameter: 2.75"
  • Outside cylinder diameter: 5.00"
  • Cylinder effective area: 9.63 (square in.)
  • Stroke: 6.25"
  • Min height: 11.13"
  • Max height: 17.38"
  • Oil cap: 69.06 (cubic in.)
  • Cylinder bore diameter: 3.75"
  • Outside piston diameter: 3.13"
  • Outside cylinder diameter: 5.00"
  • Cylinder effective area: 11.05 (square in.)


• Download the cylinder spec pdf HERE
• Download the pump compatibility pdf HERE


• Shipping weight: (2-3/8") 24 lbs. / (6-1/4") 51 lbs.
