iDEAL 3D HD Truck Bus Image Wheel Aligner System

Model: IWA-60-8500-HD-K


Shipping upgrades offered in cart page



Introducing the iDEAL 3D HD Truck Bus Imaging Wheel Alignment System! This economical & advanced system provides multi-axle wheel alignment for a variety of large vehicles such as trucks, semi-trailers, and buses with no need of a vehicle lift. While the wide scope technology allows it to read over a large range of lengths and wheelbases, it also provides real-time measurements for improved productivity. The user-friendly features such as precise & easy to understand instructions, illustration diagrams, & an integrated help system make this unit a must have for any heavy duty aligner. Order this amazing alignment system today!

• 8 compact lightweight targets
• Drive-over cable plates included
• Wireless remote control operation
• Recalls/prints current & past info
• Illustration diagrams & help system
• Integrated quick reference database
• Convenient customer database feature
• High res / extended range 3D tower cameras
• Convenient storage stands for wheel clamps
• Dual towers provide max view range up to 50 ft.
• Live reading screens for front/rear axle readings
• Designed to measure long vehicles & vehicles with trailers
• Mobile cabinet allows for side or front centered placement
• Multi-axle floor alignment system - no vehicle lift required
• Dynamic LED tower guide changes shape to guide technician

• Windows PC
• Wheel chock
• Brake depressor
• Inkjet color printer
• Steering wheel holder
• Flat panel LCD monitor
• Drive-over cable plates
• Console keyboard & mouse
• Tower concrete anchor bolts
• UPS w/ AVR (auto voltage regulation)
• Storage cabinet w/ swivel poly casters
• 2x Camera towers
• 8x 15"-27" wheel clamps
• 8x Compact style targets
• 2x Wheel clamp storage stands
• 2x HD 11K 17" dia. turntables
• 2x 43" long drive-on floor ramps
• 4x High res 3D extended range industrial cameras

• Software updates available on an annual basis
• Free phone technical support for initial setup & operational instructions
• Manufacturer defect warranty: 1 year limited parts & labor

• Our supplier does not accept returns on this item
• In event of warranty claim, replacement part(s) will be sent

Show more



• Download the manual HERE


• Does NOT ship free
• Ships 1,285 lbs. as 3 pieces
• Ships to business w/ forklift
• Residential deliveries cost extra
• Can be picked up at local truck dock terminal
