Model: ERV0200003
Usually Ships Within
The EMAX 20hp 3PH, 86CFM @ 100 PSI Rotary Air Compressor features standard advanced variable speed drive technology. Variable speed gives our customers up to 7X starting amp savings and up to 40% savings while the unit is in operation. Highly efficient Precision German engineered rotary air end provides maximum discharge, with up to 70,000 running hours. Heavy duty sound attenuated cabinet provides lower operating noise levels. We use High Efficiency motors constructed with superior materials, higher service factors, longer bearing lives, lower waste- heat output and less vibration. These rotaries are controlled by a user friendly Logika PLC (Programmable Logistic Controller). This controller makes this unit bullet proof. These controllers have may many features that are extremely user friendly and easy to use. Spin-Tek™ Design = Unique easy access oil filters & air/oil separators, requires no tools to remove/install saving time and money. Order yours today!
KEY BENEFITS• Air Differential Control• On-line demand for high air demands• Programmable Daily/ weekly schedules
Show more
230V Model• HP: 20• Voltage +/- 10%: 230• Phase: 3• Drive Type: Electric• CFM: 85• Silent Air: N• Smart Air: Y• Compressor Type: ROTARY• Motor Type: TEFC• Duty Cycle: 1• Belt Count: 3• Pump Stage: 1• Pump Riser: N• Belt Tensioner: N• Mag Starter: N• Radiator: N• Continuous Run: N• Peak Starting Amps: 331• Motor RPM: 1750• FLA + 1.15 Service Factor: 57.5• Locked Rotor Amps: 331• Recommended Breaker: 65• Max PSI: 167• Overall dims: 38" x 31" x 49"• Oil Capacity: 1.5• Oil U/M: Gallons• Estimated Pump Life (Hours): 100000
460V Model• Voltage +/- 10%: 460• CFM: 106• Peak Starting Amps: 165• FLA + 1.15 Service Factor: 27.6• Locked Rotor Amps: 165• Recommended Breaker: 30
• View the EMAX warranty programs HERE
• 208V model ships 866 lbs. at 48" x 43" x 64"• 460V model ships 880 lbs. at 55" x 58" x 55"• Residential deliveries cost extra• Free shipping to a business with forklift on site• Local dock pickup saves residential delivery fees• Free shipping applies to $450 maximum. If shipping exceeds this amount a surcharge may be needed
