Kernel 9K Lb Symmetric Floorplate 2 Post Lift

Model: TP9KF-TUX

Please Choose:

Capacity
Brand
Type
Optional Lift Accessories

A generic image
Add RE-RD8 Gallon Oil Drain

A generic image
Add RE-RD30 Self Evacuating Oil Drain

A generic image
Add ODT-30-E Self Evac Vac Oil Drain

A generic image
Add RE-AJS Auxiliary Jack Stand

A generic image
Add Two RE-AJS Auxiliary Jack Stands

A generic image
Add RE-LD Transmission Jack

A generic image
Add TJ500 Transmission Jack

A generic image
Add TJ500DT Transmission Jack

A generic image
Add TJ2KDT Transmission Jack

A generic image
Add RESS1 Under Hoist Stand

A generic image
Add Two RESS1 Under Hoist Stands

A generic image
Add Pair of Redline 12” Foam Door Protectors

Shipping upgrades offered in cart page

$3,699.99
delivery icon

Usually Ships Within

24-48 Hrs

Description

The Kernel 9,000 lb. capacity two-post floorplate style lift is designed for use in areas with limited ceiling heights. Just like the 9,000 lb. capacity clearfloor model, this symmetric column design lift has a heavy-duty leaf chain, steel pulleys, and high-strength cable equalization system but it is only 112" tall. It comes with a 220 Volt power unit which is easily adaptable to most commercial applications and is finished with a durable scratch resistant powder-coat. Order your Kernel lift today!

KEY BENEFITS
• Symmetric arms
• 9,000 lbs capacity
• Black color standard
• Chain drive cylinders
• Dual point lock release
• Auto arm restraint system
• Low profile drop-in lift pads
• Saddle pad adapters (1 Pair)
• Stackable adapters included
• Ideal for auto passenger cars
• Powder coated finish looks great and resists rust

RETURNS
• Our supplier does not accept returns on this item
• In event of warranty claim, replacement part(s) will be sent

Show more

Specs

• Lifting Speed: 50S
• Min. Pad Height: 4″
• Height Overall: 112″
• Max Lift Height: 72″
• Narrow Bay Setting: NA
• Max Load Per Arm: 2,250 lbs.
• Power: 220V – 20 AMP – 1PH
• Width Overall w/ Power Unit: 141″
• Width Between Columns: 110-3/8″
• Drive Thru Clearance: 101-11/16″
• Asymmetric / Symmetric: Symmetric
• Clear Floor / Floor Plate: Floor Plate
• Short Arm Reach – min/max: 31″-45″
• Long Arm Reach – min/max: Same

Downloads

• Download the pdf manual HERE
• Download the spec sheet HERE
• View our install blog HERE

• Download the How to Install a Two Post Auto Lift Manual HERE



Shipping

• Ship weight: 1,295 lbs
• Residential deliveries cost extra
• Ships LTL truck freight to business w/ forklift
• Can be picked up at local truck dock terminal
• Call for availability at locations - pickup fees apply
• Free shipping applies to $700 maximum. If shipping exceeds this amount a surcharge may be needed
• Pickup at satellite warehouses:
- Temecula, CA  92590
- Marshalltown, IA 50158
- Elwood, IN 46036
- Bow, NH 03304
- Wilmington, DE 19802
- Reidsville, NC 27320
- Orlando, FL 32809
- Lowell, MA 01852
- Southfield, MI 48033 (no customer pick-ups allowed)
- Alvarado,  TX  76009

Videos

Reviews

Ask & Answer

  • m.hosseini Nov 05, 2023
    Q. How to determine the weight of the car before using the TP9KF-TUX?
    A. Most truck stops have scales that will weigh an entire vehicle and only costs about $10. I'm sure you have one in your area. Thanks for your question!
