Redline 10 Ton Benchtop Hydraulic Shop Press

Model: RE10T

(2 reviews)

Optional Accessories

Pin Press Kit

Reg. $369.50 Sale price $349.50
5% off


This industrial Redline 10 ton hydraulic shop press is a manual operation hydraulic pressing machine perfect for manufacturing, auto repair, or general mechanical work. It features a pump capable of manual operation. The ram cylinder is capable of moving left to right as it sits on a small track. Included with the 10 ton shop press is a tonnage gauge to easily read how much pressure is being used. Order your new 20,000 pound capacity hydraulic shop press today from Redline Engineering!

• CE Certified
• 10 ton capacity
• Powder coated finish
• 9-3/4" movement of carriage up and down
• 3 height adjustments of 3-1/4" increments
• Ram cylinder capable of shifting both left and right
• Pressure gauge accurate +/- 2.5% of press capacity
• Manual pump powered hydraulic cylinder for everyday pressing

Often misspelled as 'hydrolic', this hydraulic shop press is best for pressing wheel bearings as it helps apply a lot of force when manual options are not working.

• Each press plate is rated to ½ the tonnage of the press; thus, if applying the press’ maximum force, the load must be distributed over both press plates to avoid damaging the press

Show more


• Handle length 19"
• Leg length 19-1/2"
• Cylinder stroke 7"
• Inside frame width: 13-3/8"
• Carriage pin diameter: 3/4"
• Main frame is 2-3/4" x 1/4"
• Pump fluid volume: 17.9 fl oz.
• Cylinder ram diameter 1-9/16"
• Interior carriage width: 4-9/16"
• Interior carriage length: 10-1/8"
• Internal cylinder diameter: 1.77"
• Piston retraction time: 14 seconds
• Pressure gauge accurate to +/- 2.5%
• Maximum pump pressure: 8939 PSI
• Cylinder piston/bore diameter: 1.77165"
• Overall dims 26-1/2" L x 19-1/2" W x 41-1/2" H
• Middle carriage 18-7/8" L x 5-7/8" W x 3-1/8" H
• Approximate number of pumps to full range without load: 118
• Two heavy duty press plates 6-11/16" L x 4" W x 3/4" thickness
• Work dims between cylinder and press plates:
-Min height from cylinder: 6-7/8"
-Max height from cylinder: 13-1/2"


• Download the manual pdf HERE


• Ships via FedEx
• Ships 114 lbs. at 31" W x 21" L x 6" H



5.0 / 5 (2 reviews)
Based on 2 Reviews Write review
  • I wish I would’ve bought one years ago I got it today but togeth Apr 9, 2018


    Apr 9, 2018
    I wish I would’ve bought one years ago I got it today but together tried it out it works better than I ever imagined thank you
  • carlhil2 Apr 6, 2018

    Rosin Press

    Apr 6, 2018
    I bought this press for my Dabpress Rosin plates,. it was easy to assemble. compact and it seems sturdy enough for constant 3-5 ton presses. I put wheels on mine and I am very satisfied so far. would recommend to anyone...
