Model: RE20T-A-HD
In Stock in
Usually Ships Within
This industrial strength heavy duty Redline 20 ton hydraulic shop press is an air over hydraulic pressing machine perfect for manufacturing, auto repair, or general mechanical work. It features a pump capable of manual operation, as well as it can be powered via compressed air. Standard features include a tonnage gauge, capability to move the ram cylinder from left to right, and 9 different height adjustments for both small and large projects. Order your new 40,000 pound capacity hydraulic shop press today from Redline Engineering!
KEY BENEFITS
• Covered by Redline's 1-Year parts warranty• CE Certified• 20 ton capacity• Powder coated finish• 39-3/8" movement of carriage up and down• 9 height adjustments of 4-3/8" increments• Ram cylinder capable of shifting both left and right• Pressure gauge accurate +/- 2.5% of press capacity• Air powered hydraulic cylinder for heavy duty pressing
HEAVY DUTY BENEFITS• HD upgrades over regular RE20T-A• Upgraded cylinder slide system• Handle shifts cylinder left/right• Welded frame does not bolt together• Optional adjustable safety grid guard• Utilizes carriage pins with anti-sliding flower clips• Press plates include locking pins & round stock mounts
One of our best hydraulic shop presses—which is often misspelled as a “hydrolic” press—is great for pressing wheel bearings where tons of force is needed.
PRESS PLATE RATING• Each press plate is rated to ½ the tonnage of the press; thus, if applying the press’ maximum force, the load must be distributed over both press plates to avoid damaging the press
Show more
• Leg length 22"• Hose length 52"• Handle length 27-3/8"• Cylinder stroke 7-1/4"• Carriage pin diameter: 1"• Inside frame width: 20-1/8"• Cylinder ram diameter 1-7/8"• Main frame is 2-3/8" x 5/16"• Interior carriage width: 6"• Interior carriage length: 10-1/2"• Internal cylinder diameter: 2.36"• Operates at a 75dB sound rating• Piston retraction time: 32 seconds• Pressure gauge accurate to +/- 2.5%• Air motor requires 7 CFM of air supply• Cylinder piston/bore diameter: 2.3622"• Overall dims 31-3/4" L x 22" W x 63-1/2" H• Middle carriage 24-3/4" L x 6-7/8" W x 6" H• Air pump full range without load: 65 seconds• Approximate number of pumps to full range without load: 189• Two heavy duty press plates 7-3/4" L x 4-3/4" W x 1-1/8" thickness• Work dims between cylinder and press plates:-Min height from cylinder: 1/4"-Max height from cylinder: 35"
• Download the manual pdf HERE
• Residential deliveries cost extra• Ships to commercial location w/ forklift• Ships 367 lbs. at 67" W x 28" L x 11" H• Units available in Pensacola, FL with rebate• Pensacola, FL pickups – read our policies HERE• Free shipping applies to $200 maximum. If shipping exceeds this amount a surcharge may be needed
